OS-VSR Heliport Controller

Short Description:

Altiglo OS-VSR heliport controller sets a new standard for heliport lighting management, offering unmatched performance, reliability, and ease of use. With its advanced features and robust design, it is the ideal choice for any heliport seeking a superior lighting control solution.

Power voltage:12VDC, 48VDC, 110VAC

Power Consumption:5W

Maximum Load: 5KW

Number of Light output:10 way

Materials:Stainless steel 304

IP rate:IP66

Item: OS-VSR

POWER SUPPLY - Operating voltage: 220VAC, 50Hz

Downloads

Send Enquiry

SKU: OS-VSR

Item	OS-VSR
POWER SUPPLY - Operating voltage	220VAC, 50Hz
Power Consumption	5W
OPERATION - Maximum Load	5KW
Number of lighting control	Regular 8/10/12circuits
Control mode	Switch on /off the devices separately, or switch all devices with one button
Surge device	Overload and over-voltage protection
Wireless Remote Control	Optional
MECHANICAL STRUCTURE - Product Life Expectancy	Average 5 years
Number of Light output	10 way
Ambient Temperature	-40℃～+55℃
Humidity	0~95%
Wind Speed	80m/s
Install	Wall-mounted
Material	Stainless steel 304
IP Standard	IP66
Overall size(mm)	400＊300＊180mm
