TL78 LED Marine Light(3-5nm)

Short Description:

Product name: LED Marine Light Steady Type or Flashing Type(Optional)

Input voltage: 110-220VAC, 50/60 Hz;12VDC;24VDC;30-60VDC

Visible range: 3-5nm

LED Lifespan: 100,000 Hours

Materials: Lens-PC; Body-Aluminum

Item: TL78

ELECTRICAL CHARACTERISTIC - Visible distance: >3-5nm

Downloads

Send Enquiry

Item	TL78
ELECTRICAL CHARACTERISTIC - Visible distance	>3-5nm
Vertical Divergence	10 Degree
Horizontal out-put	360 Degree
LED Color	Red, yellow, white, green or blue
LED Lifespan	100, 000 Hours
OPERATION - Woke mode	Flashing
Flash Pattern	Flashing: 20/30/40/60FPM; Default: 40FPM; Steady burning
Flash duration	670ms
Photocell sensitivity	70-100 Lux
POWER SUPPLY - Input voltage	85-265VAC, 50/60 Hz; 12VDC; 24VDC;30-60VDC;
Power consumption	5W (Steady burning)
MECHANICAL STRUCTURE - Lens	Polycarbonate, UV Stabilize
Body	Die-casting Aluminum
IP Ingress	IP67
Weight	3KG
Operating Temperature	-40℃ ~ +55℃
Storage Temperature	-40℃ ~ +70℃
Wire Connection mode	Pre wired
Relative humidity	0-95% RH non-condensing
Wind speed	Up to 150mph(240kph)
OTHERS - Warranty	2 years
Optional	Flashing pattern(20–60FPM) Built-in photocell
