Explosion-Proof Marine Lantern, LED Marine Lanterns
Short Description:
Altiglo VX-RB80 Explosion proof Led Marine Light is specifically designed and manufactured to meet the rigorous demands of maritime industry, providing an added layer of safety and protection for vessels operating in hazardous areas where flammable gases or dust may be present. With its robust construction and adherence to international safety standards, the Maring grade explosion proof navigation light offers peace of mind to ship owners and operators, knowing that their vessels are equipped with a reliable and safe signaling solution.
Power consumption:20W
Visible distance:>5-7NM
Autonomy:20 days(flashing), 10 days(steady burning)
Item: VX-RB80
ELECTRICAL CHARACTERISTIC - Visible distance: >5-7NM
Downloads
VX-RB80| Item | VX-RB80 |
|---|---|
| ELECTRICAL CHARACTERISTIC - Visible distance | >5-7NM |
| Vertical Divergence | 10 Degree |
| Horizontal out-put | 360 Degree |
| LED Color | Optional red , white, yellow, green and blue |
| LED Lifespan | 100, 000 Hours |
| OPERATION - Woke mode | Flashing or steady burning |
| Flash Pattern(optional) | Flashing: 20/30/40/60FPM; Default: 40FPM; |
| Photocell sensitivity | 70-100 Lux |
| Autonomy | 20 days(flashing), 10 days(steady burning) |
| Alarm type: | NO & NC, dry contact relay(optional) |
| POWER SUPPLY - Working voltage | 85-265VAC, 9V-30VDC, 30-60VDC; |
| Power consumption | 20W |
| MECHANICAL STRUCTURE - Lens | Tempered glass |
| Body | Aviation yellow powder-coated extruding aluminum |
| IP Ingress | IP66 |
| Weight | 3 KG |
| Operating Temperature | – 4 0℃ ~ +70℃ |
| Storage Temperature | – 4 0℃ ~ +55℃ |
| Suitable areas: | Exde‖CT6/DIP A20，TA，T6 |
| Corrosion grade | WF1*WF2 |
| Wind speed | Up to 150mph(240kph) |
| Wiring Cable gland | G3/4″ entry cable gland, suitable for 10mm-14mm cable |
| Light Dimension(mm ） | 170X300X235 |
| Packing dimension(mm ） | 300 × 200 × 190 |
| OTHERS - Warranty | 1 years |
Typically specified for Explosion-Proof Marine Lantern, LED Marine Lanterns projects.
Common use cases include explosion proof marine lantern, led marine lanterns, products.
Need Product Guidance?
Request pricing, lead times, technical compatibility guidance, and project support for this model.
