OS-VHF Wireless Control System User Manual
Short Description:
Product name: Wireless Helipad Radio Controller
Power voltage:110-240VAC (Other Voltage can be customized)
Power Consumption:≤30W
Acceptance frequency: 118-136MHZ (The default factory setting is 128.00MHz.)
Ambient temperature: -40˚C ~ 85˚C
Materials:Cold rolled steel or Stainless steel
IP rate:IP65
Item: OS-VHF
POWER SUPPLY - Voltage: 110-240VAC (Other Voltage can be customized)
Downloads
- SKU
OS-VHF
- Item: OS-VHF
- POWER SUPPLY - Voltage: 110-240VAC (Other Voltage can be customized)
- Power consumption: ≤30W
- OPERATION - Acceptance frequency: 118-136MHZ (The default factory setting is 128.00MHz.)
- Transmit frequency: 137-174/400-470MHZ
- MECHANICAL STRUCTURE - Overall size: 600 × 400 × 1300（mm）
- Ambient temperature: -40˚C ~ 85˚C
- Working humidity: 0% ~ 95%
| Item | OS-VHF |
|---|---|
| POWER SUPPLY - Voltage | 110-240VAC (Other Voltage can be customized) |
| Power consumption | ≤30W |
| OPERATION - Acceptance frequency | 118-136MHZ (The default factory setting is 128.00MHz.) |
| Transmit frequency | 137-174/400-470MHZ |
| MECHANICAL STRUCTURE - Overall size | 600 × 400 × 1300（mm） |
| Ambient temperature | -40˚C ~ 85˚C |
| Working humidity | 0% ~ 95% |
| Wind Speed | 80m/s |
| IP Ingress | IP65 |
| Material | Cold rolled steel or Stainless steel |
| Product Life Expectancy | Average 5 years |
| Product weight | 50kg |
| OTHERS - Compliance standards | ICAO / CAAC / meets the requirements of FAA (advisory Circular AC 150/5345-49) Type I and Type A. |
| Precautions | Do not press the microphone call button when the antenna is not connected! |
Common use cases include heliport lighting, products.
