Short Description:
Solar panel: 12V/2.5W(Single side)
LED Life Time:100,000Hours
Color: White
IP grade: IP68
Item: QCL590-L-S-RE
E LECTRICAL CHARACTERISTIC - Illumination: Ultra-bright LEDs and NVG-compatible infrared (IR) LEDs(optional)
Downloads
QCL590-L-S-RE| Item | QCL590-L-S-RE |
|---|---|
| E LECTRICAL CHARACTERISTIC - Illumination | Ultra-bright LEDs and NVG-compatible infrared (IR) LEDs(optional) |
| Light intensity | ≥ 125 cd |
| Beam angle | Uni-directional |
| LED Color | White |
| LED Lifespan | 100, 000 Hours |
| OPERATION - Woke mode | Adjustable flashing and fixed mode |
| Autonomy | 60 hrs(at max intensity ， authomony can be changed accroding to the light intensity |
| POWER SUPPLY - Solar panel | 12V/2.5W(Single side) |
| Solar Efficiency | 21% |
| Battery parameters | High-efficiency 12V24Ah Lithium |
| Frequency | Lora 433MHZ |
| B attery replacement | Replaceable |
| MECHANICAL STRUCTURE - Lens | Polycarbonate, UV Stabilize |
| Body | Aviation yellow powder-coated extruding aluminum |
| IP Ingress | IP6 8 |
| Weight | 4.8 KG |
| Operating Temperature | -40℃ ~ +55℃ |
| Storage Temperature | -40℃ ~ + 55 ℃ |
| Relative humidity | 0-95% RH non-condensing |
| Wind speed | Up to 150mph (240kph) |
| Dimensions | 254mm H, 234mm Diameter |
| OTHERS - Warranty | 2 years for light 1 year for battery |
| Optional | GPS Synchronization function |
Common use cases include airport lighting, portable solar airfield lighting, products.
