Low Intensity Series
WL90S-F Low Intensity Single Obstruction Light (Type A)
Whether you are a commercial airport, helipad, or private airstrip, our WL90S-F LED Low…
SKU WL90S-F
Short Description:
Our latest innovation in marine safety lighting – the Solar Powered Marine Light!
This revolutionary product is designed to enhance visibility and safety for marine
vessels, docks, and waterways.Powered by the sun, this marine light is environmentally friendly and cost-effective,making it the ideal solution for any
waterfront property.
Solar panel: High efficient mono-crystalline silicon 5V4.8 Watts
Battery capacity: 3.6V8AH rechargeable NiMH battery
Nominal Night Range: 3-4nm
Autonomy: 10 days (flashing); 3-4 days(fixed)
Materials: Lens-PC Body-Aluminum
Item: SB78
ELECTRICAL CHARACTERISTIC - Visible distance: >3-4nm
Downloads
SB78| Item | SB78 |
|---|---|
| ELECTRICAL CHARACTERISTIC - Visible distance | >3-4nm |
| Vertical Divergence | 10 Degree |
| Horizontal out-put | 360 Degree or 112 degree |
| LED Color | Red (for obstruction). White, yellow, green and blue are available for other applications |
| LED Lifespan | 100, 000 Hours |
| OPERATION - Woke mode | Flashing or steady burning |
| Flash Pattern(optional) | Flashing: 20/30/40/60FPM; Default: 40FPM; |
| Flash duration | 670ms |
| Photocell sensitivity | 70-100 Lux |
| Autonomy | 15 days(flashing), 3-4 days(steady burning) |
| Alarm type | NO & NC, dry contact relay(optional) |
| POWER SUPPLY - Solar panel | Solar module, mono-crystalline silicon 5V 4.8W |
| Solar Efficiency | 21% |
| Battery capacity | NIMH, 3.6V/8Ah |
| Battery replacement | Replaceable |
| MECHANICAL STRUCTURE - Lens | Polycarbonate, UV Stabilize |
| Body | Aviation yellow powder-coated extruding aluminum |
| IP Ingress | IP67 |
| Weight | 2KG(Polycarbonate base) 3KG(Aluminum base) |
| Operating Temperature | -30℃ ~ +55℃ |
| Storage Temperature | -40℃ ~ +55℃ |
| Suitable areas | PSH≥3 |
| Relative humidity | 0-95% RH non-condensing |
| Wind speed | Up to 150mph(240kph) |
| Atmospheric Transparency Coefficient | 0.85 |
| OTHERS - Warranty | 2 years for light |
Common use cases include led marine lanterns, products, solar powered marine lanterns.
Need Product Guidance?
Request pricing, lead times, technical compatibility guidance, and project support for this model.
